| Property | Testmethod | Typical data |
| Tensile strength (Mpa) | ASTM D 2671 | ≥13 |
| Elongation at break (%) | ASTM D 2671 | 300 |
| Tensile strength after aging (120℃/168hrs) (Mpa) | ASTM D 2671 | 10 |
| Elongation at break after aging (120/168hrs) (%) | ASTM D 2671 | 250 |
| Dielectric strength (kV/mm) | ASTM D 2671 | 15 |
| Electric constant (ε ) | IEC250 | 3 |
| Volume resistance (Ω.cm) | ASTM D 2303 | >1013 |
| Flammability (Oxygen index) | IEC 93 | 25 |
| Copper corrosion (120/168hrs) | ASTM D 2671 | No corrosion |
| Water absorption (%) | ISO 62 | 1(max) |
| Specialisation | AS supplied (mm) | After recovered (mm) | ||||||||||
| Branch | Root | Branch | Root | |||||||||
| I.D. | Wall thickness | Length | I.D. | Wall thickness | Length | I.D. | Wall thickness | Length | I.D. | Wall thickness | Length | |
| 2ZT1–41/18 | ≥18 | 1.2 | 42 | ≥41 | 2.2 | 65 | ≤5.3 | 2.3± 0.3 | 45 | ≤19 | 2.4± 0.3 | 68 |
| 2ZT2–56/22 | ≥22 | 1.4 | 44 | ≥56 | 2.3 | 78 | ≤8.5 | 2.3± 0.3 | 47 | ≤24 | 2.5± 0.3 | 81 |
| 2ZT3–68/27 | ≥27 | 1.7 | 50 | ≥68 | 2.7 | 95 | ≤14 | 2.6± 0.3 | 53 | ≤38 | 3.2± 0.3 | 98 |
| 3ZT00–42/16 | ≥16 | 1.8 | 50 | ≥42 | 2 | 75 | ≤5.5 | 2.6± 0.3 | 53 | ≤20 | 3.2± 0.3 | 78 |
| 3ZT00–50/24 | ≥24 | 2 | 50 | ≥50 | 2.1 | 100 | ≤8.0 | 3.2± 0.3 | 53 | ≤25 | 3.5± 0.3 | 103 |
| 3ZT1–75/32 | ≥32 | 2.1 | 68 | ≥75 | 2.5 | 122 | ≤10 | 3.4± 0.3 | 71 | ≤35 | 4.0± 0.3 | 125 |
| 3ZT2–85/40 | ≥40 | 2.2 | 75 | ≥85 | 2.8 | 125 | ≤15 | 3.5± 0.3 | 78 | ≤41 | 4.2± 0.3 | 128 |
| 3ZT3–110/48 | ≥48 | 2.3 | 80 | ≥110 | 2.8 | 125 | ≤17 | 3.7± 0.3 | 83 | ≤50 | 4.2± 0.3 | 128 |
| 3ZT4–120/55 | ≥55 | 2.7 | 80 | ≥120 | 3 | 135 | ≤22 | 4.3± 0.3 | 83 | ≤55 | 4.3± 0.3 | 138 |
| 4ZT0–32/11 | ≥11 | 2 | 42 | ≥32 | 2.5 | 90 | ≤5.0 | 2.4± 0.3 | 45 | ≤16 | 3.0± 0.3 | 93 |
| 4ZT1–45/16 | ≥16 | 2.1 | 55 | ≥45 | 2.6 | 95 | ≤6.0 | 2.8± 0.3 | 58 | ≤20 | 3.5± 0.3 | 98 |
| 4ZT2–60/25 | ≥25 | 2.2 | 63 | ≥60 | 2.7 | 110 | ≤8.0 | 3.6± 0.3 | 66 | ≤27 | 3.6± 0.3 | 113 |
| 4ZT3–70/30 | ≥30 | 2.2 | 73 | ≥70 | 2.8 | 120 | ≤11 | 3.6± 0.3 | 76 | ≤33 | 3.6± 0.3 | 123 |
| 4ZT4–85/37 | ≥37 | 2.2 | 75 | ≥85 | 2.7 | 125 | ≤12 | 3.6± 0.3 | 78 | ≤39 | 3.7± 0.3 | 128 |
| 5ZT0–32/11 | ≥12 | 1.7 | 40 | ≥38 | 2.4 | 75 | ≤4.0 | 2.8± 0.3 | 43 | ≤18 | 3.2± 0.3 | 78 |
| 5ZT1–45/16 | ≥15 | 2.2 | 75 | ≥53 | 2.5 | 90 | ≤6.0 | 3.4± 0.3 | 78 | ≤25 | 3.4± 0.3 | 93 |
| 5ZT2–60/25 | ≥26 | 2.3 | 80 | ≥80 | 2.5 | 100 | ≤9.0 | 3.4± 0.3 | 83 | ≤38 | 3.4± 0.3 | 103 |
| 5ZT3–70/30 | ≥30 | 2.3 | 75 | ≥92 | 2.5 | 105 | ≤12 | 3.5± 0.3 | 78 | ≤42 | 3.6± 0.3 | 108 |
For more detailed information about our products, please feel free to contact us for a quote.
We offer customized solutions specifically built to meet your exact specifications, environment and performance goals.
